Description
Pacer RX-5 has been discontinued and is no longer available. It was the water-thin grade in Pacer’s RX Series Range Extended line, a non-surface-sensitive ethyl hybrid cyanoacrylate at 2 to 10 cP with .002 in gap capability, supplied in a 1 lb bottle as part number FG04053. This page stays up because the specifications are still useful if you have material on the shelf, and because there is no straight one-for-one replacement, so choosing what to move to takes a decision rather than a substitution.
What to Use Instead
RX-5 did two things at once: it wicked into tight joints, and it bonded surfaces a conventional cyanoacrylate cannot. No grade currently in the Pacer line does both. You have to decide which property matters more for your part.
| If you need | Use | What you give up |
|---|---|---|
| The non-surface-sensitive chemistry, on oily, plated, porous, or acidic parts | Pacer RX-50, 30 to 70 cP | Wicking. At 30 to 70 cP it will not draw into a closed joint by capillary action, and gap capability drops from .002 in to .004 in |
| The water-thin wicking behavior, at the same .002 in gap | Pacer E-5, 2 to 10 cP | Surface tolerance. E-5 is a general purpose grade, so it will struggle on the contaminated and acidic surfaces RX-5 handled |
| Range Extended chemistry in a 1 lb bottle, as RX-5 was supplied | Pacer RX-100, 1 lb | Viscosity. At 80 to 120 cP it is far thicker than RX-5, though it fills a wider .005 in gap |
| Both properties together | Call us | Nothing in the current Pacer line covers it. We stock other manufacturers and can look at what fits |
If RX-5 was in a qualified process, the second row is usually the wrong move, because swapping a non-surface-sensitive grade for a general purpose one is a chemistry change on the property you were paying for. Talk to us before you requalify. Call (800) 220-1966 or email [email protected].
Pacer RX-5 Specifications, For Reference
Retained for anyone holding remaining stock or comparing against a replacement grade.
| Property | Value |
|---|---|
| Status | Discontinued |
| Chemistry | Ethyl hybrid cyanoacrylate |
| Grade | Range Extended, RX Series |
| Surface Sensitivity | Virtually non-surface sensitive |
| Color | Translucent liquid |
| Viscosity | 2 to 10 cP |
| Typical Gap | .002 in |
| Fixture Time | 1 to 5 minutes |
| Strength Development | 80% of full strength in 15 to 30 minutes |
| Cured Temperature Range | -65F to +180F (-54C to 82C) |
| Softening Point | 311F / 155C |
| Melting Point | 365F / 185C |
| Glass Transition | 347F / 175C |
| Flashpoint | 185F / 85C |
| Specific Gravity | 1.04 |
| Vapor Pressure | 8 mmHg at 70C |
| Rockwell Hardness | M 75 |
| Outgassing | 0 (at 10^-6 mmHg, 72F) |
| Dielectric Constant | 3.98 at 1 MC |
| Volume Resistivity | 8.4 x 10^12 ohm-cm |
| Tensile, Steel | 4000 psi (+/- 10%), ASTM D-2095 |
| Soluble In, Liquid State | Acetone, MEK |
| Soluble In, Cured State | Pacer X-9 Debonder, acetone, nitropropane |
| Specification Compliance | MIL-A-46050C Type II, Class 1; A-A-3097 Type II, Class 1 |
| Shelf Life | One year, stored per the TDS |
| Size Offered | 1 lb (453 g) Bottle, FG04053 |
Shear Strength by Substrate
Tested per ASTM D-1002. Where the table reads substrate failure, the part broke before the bond did. These figures are identical across the RX Series, so they carry over to any RX grade you move to.
| Substrate | Shear Strength, psi (+/- 10%) |
|---|---|
| Steel | 2300 |
| Aluminum | 1600 |
| Copper | 1400 |
| ABS | Substrate failure |
| Rigid PVC | Substrate failure |
| Nylon | Substrate failure |
| Polycarbonate | Substrate failure |
| SBR | Substrate failure |
| EPDM | Substrate failure |
Current Pacer RX Series Grades
- Pacer RX-50 Range Extended (30-70 cP), .004 in gap, the thinnest RX grade currently offered, 20 gram bottle
- Pacer RX-100 Range Extended (80-120 cP), .005 in gap, the broad use grade, 20 gram and 1 lb
- Pacer RX-500 Range Extended, .008 in gap, 20 gram and 1 lb
- Pacer RX-700 Range Extended (600-800 cP), .010 in gap, 20 gram bottle
- Pacer RX Gel, non-sag non-running gel, .020 in gap, 20 gram and 200 gram
- Pacer E-5 Ultra-Low Viscosity (2-10 cP), the general purpose grade at RX-5’s viscosity and gap, for clean surfaces
- All cyanoacrylate instant adhesives
Frequently Asked Questions
Is Pacer RX-5 discontinued?
Yes. Pacer RX-5, part number FG04053, is no longer available. It was the 2 to 10 cP water-thin grade in the RX Series Range Extended line, supplied in a 1 lb bottle. The series now starts at RX-50 at 30 to 70 cP.
What is the replacement for Pacer RX-5?
There isn’t a direct one, and that’s worth being upfront about. RX-50 keeps the non-surface-sensitive chemistry but is four times thicker at 30 to 70 cP and will not wick into a closed joint. E-5 keeps the water-thin 2 to 10 cP behavior and the .002 in gap but is a general purpose grade with no surface tolerance. RX-100 keeps the chemistry and the 1 lb package but is much thicker again. Decide which property your part actually depends on, and call us if you need both.
Is there a non-surface-sensitive wicking cyanoacrylate available?
Not in the current Pacer line. RX-5 was that product, and the thin grades in Pacer’s MR, PX, and TX series have also been discontinued. The thinnest Range Extended grade now available is RX-50 at 30 to 70 cP. If you need to wick into a tight joint on an oily, plated, or acidic surface, call us and we’ll look at what other manufacturers offer.
Can I still get specifications for Pacer RX-5?
Yes, they’re on this page. Full liquid and cured state properties, shear strength by substrate, and specification compliance are retained above for anyone holding remaining stock or comparing against a replacement grade. If you need the data sheet or a document for a quality record, call or email us.
I have RX-5 in stock. Is it still usable?
Depends on age and storage. Pacer’s stated shelf life is one year when refrigerated unopened, or stored in a cool, dry location away from heat sources once opened. Discontinuation does not affect material you already have, but a cyanoacrylate past its shelf life typically thickens noticeably, and thickened CA has reached the end of its useful life. Test on scrap before you put it on a production part.
What size was Pacer RX-5 supplied in?
A 1 lb (453 g) bottle only, part number FG04053, UPC 0 87093 00242 5. Of the current RX grades, RX-100 and RX-500 are the two offered in a 1 lb, so those are the closest packaging match.
Questions on Fit
Need to replace RX-5 in a running process? Call (800) 220-1966 or email [email protected] and tell us the substrate and the joint. We’ll work out what fits.
