Description
tesa® ACXplus 7063 High Adhesion tape is a 32mil (0.032 Inch) deep black double-sided acrylic foam tape. It consists of a high-performance acrylic system and is primarily characterized by its bonding power, stress dissipation and its temperature and weather resistance.
Due to its unique formulation it combines a very high adhesion level with a very good resistance against plasticizer migration. It is especially designed for the bonding of “hard-to-bond-materials” such as powder coatings or plastic materials. Even for combinations of such materials with all kind of metals, or metal/metal bonding, it offers a convenient solution due to high process safety.
The visco-elastic, foamed acrylic core compensates different thermal elongation of bonded parts. The product provides a very high immediate tack and peel adhesion.
Technical Properties
| Backing material | Foamed Acrylic |
| Color | Deep Black |
| Total Thickness | 32 mils (0.032″) |
| Type of Adhesive | Tackified Acrylic |
| Elongation at break | 600% |
Adhesion Properties
| Adhesion to Aluminium (after 3 days) | 292.35 oz/in |
| Adhesion to Glass (after 3 days) | 292.35 oz/in |
| Adhesion to PMMA (after 3 days) | 246.67 oz/in |
| Adhesion to Steel (after 3 days) | 274.08 oz/in |
Properties
| Temperature Resistance (short term) | 338°F |
| Temperature Resistance (long term) | 158°F |
| Tack | Very Good |
| Ageing Resistance (UV) | Very Good |
| Humidity Resistance | Very Good |
| Resistance to Chemicals | Very Good |
| Softener Resistance | Very Good |
| Static Shear Resistance at 73.4°F | Very Good |
| Staic Shear Resistance at 158°F | Good |
| T-block | Good |
PV 22 = White PE coated paper liner tesa® ACXplus branded
PV 24 = Blue filmic liner
Adhesion values to PMMA, glass and aluminum are not part of the product specification.
tesa® ACXplus 7063 is recognized according to UL Standard 746C. UL File QOQW2.E309290
