Description
Chem-Set VST 7816 is a 16 mil thick, highly conformable acrylic foam tape engineered for strong bonding to low surface energy substrates. It delivers strong adhesion to difficult materials including polypropylene, polyethylene, ABS, powder-coated metals, clearcoats, and ceramic-coated automotive panels. The tape uses a double-coated pure acrylic adhesive system that delivers excellent initial tack, high shear strength, and long-term durability without requiring primers on LSE surfaces.
VST 7816 is ideal for automotive trim, plastics assembly, powder-coated components, outdoor signage, and general manufacturing applications where thin, conformable, primerless LSE bonding is required.
Available in black, grey, or white to match substrate aesthetics.
Key Features and Benefits
-
Designed for bonding low surface energy substrates including PP, PE, ABS, and powder coat
-
Primerless LSE adhesion eliminates the need for surface activators
-
16 mil conformable acrylic foam adapts to irregular surfaces
-
High shear strength and long-term outdoor durability
-
Strong initial tack for production-speed assembly
-
Excellent UV, temperature, and weather resistance
-
Suitable for automotive, signage, industrial, and OEM applications
-
Available in black, grey, and white
Common Applications
-
Automotive trim, nameplates, and exterior plastics
-
Powder-coated metal bonding
-
Low surface energy plastics including PP, PE, ABS
-
Outdoor signage and panel assemblies
-
Painted or clear-coated substrates
-
Industrial plastic fastening without mechanical fasteners
Technical Specifications
(Values taken from the supplied datasheet and rewritten under Chem-Set branding)
Performance
| Property | Value | Test Method |
|---|---|---|
| Peel Adhesion (SST) | 23 N/10 mm (13 lb/in) | ASTM D3330 |
| Peel Adhesion (ABS) | 35 N/10 mm (20 lb/in) | ASTM D3330 |
| Peel Adhesion (PP) | 12 N/10 mm (7 lb/in) | ASTM D3330 |
| Normal Tensile | 540 kPa (78 psi) | ASTM 897 |
| Dynamic Shear | 560 kPa (81 psi) | ASTM 1002 |
| Static Shear | >10,000 min at 22 C | ASTM 3654 |
Physical Properties
| Property | Value |
|---|---|
| Thickness | 0.016 inch (16 mils) ± 15 percent |
| Density | 720 kg/m³ (45 lb/ft³) |
| Colors | Black, Grey, White |
| Adhesive System | Double-coated acrylic |
| Foam Core | High conformable acrylic foam |
| Liner | Siliconized red PE film |
Temperature Resistance
| Condition | Rating |
|---|---|
| Long Term | 176 F (80 C) |
| Short Term | 212 F (100 C) |
| Minimum Temperature | -40 F (-40 C) |
Storage & Shelf Life
| Property | Value |
|---|---|
| Storage Conditions | 40 to 95 F (5 to 35 C) |
| Shelf Life | 24 months |
Available Sizes
Standard Slit Rolls
-
1/2 inch x 36 yd
-
3/4 inch x 36 yd
-
1 inch x 36 yd
Log Rolls
-
900 mm x 36 m (convertible to any width upon request)
Chem-Set LSE High Bond Tape Family Cross Reference
This table helps buyers compare the Chem-Set LSE series to the 3M LSE family.
| Chem-Set Product | Thickness | LSE Class | Closest 3M LSE Equivalent |
|---|---|---|---|
| VST 7816 | 16 mils | Thin, conformable | No 3M equivalent |
| VST 7825 | 25 mils | Matches LSE-060 class | 3M LSE-060WF |
| VST 7847 | 47 mils | Matches LSE-110 class | 3M LSE-110WF |
| VST 7863 | 63 mils | Matches LSE-160 class | 3M LSE-160WF |
Why this matters:
3M does not offer a 16 mil LSE tape. VST 7816 fills this performance gap, giving manufacturers a thinner option for LSE bonding where profile height and appearance are critical.
Comparable Products
Chem-Set VST 7816 is designed for applications where buyers typically evaluate:
-
3M VHB LSE Series (LSE-060WF, LSE-110WF, LSE-160WF)
-
Automotive mounting tapes for LSE plastics
-
Primerless acrylic foam tapes for PP, PE, ABS, and powder coat
VST 7816 provides similar functional performance while offering a thin 16 mil construction not available in the 3M LSE product family.
Ordering Information
Chem-Set VST 7816 is available in three colors and multiple widths. Custom slit widths and log roll conversions are available. Contact Chemical Concepts for pricing, application testing, or technical guidance.
