Description
Undermount sink clips fasten a sink rim from below, while the CounterBalance Extended Concealed Bracket supports the work surface itself. This white 18 inch model gives fabricators a concealed structural option when the project needs a floating counter, shelf, or workstation without visible legs. It uses an upper extension for added rigidity, and the listed 1 inch format helps match the bracket to the available wall and surface geometry.
Undermount sink clips: Choosing the Correct Support Layer
Sink clips and countertop brackets solve different parts of an installation. Clips clamp the sink to the underside of stone, quartz, or solid surface. This bracket transfers overhang loads into load-bearing wall studs. Use it for deep countertop overhangs, bar seating, islands, and wide floating work surfaces. Plan the sink hardware and surface support as separate systems, then confirm that neither interferes with plumbing, cabinet rails, electrical runs, or access for future service.
The Extended Concealed Bracket mounts at the wall structure so the arm remains hidden after the surface is installed. CounterBalance guidance allows an overhang to extend up to 6 inches beyond the bracket length when the complete layout follows the applicable load and spacing guidance. Supports are commonly planned on 16 to 20 inch centers. Project loads, substrate thickness, seams, cutouts, and field conditions still determine final quantity and spacing.
Undermount sink clips: Fit, Finish, and Installation Checks
Confirm stud locations before ordering. Fasten into load-bearing wood framing or provide suitable backing for metal studs. Keep the bracket level with adjacent supports so the countertop bears evenly across the run. The white powder-coated finish suits light cabinetry and trim, while the concealed placement keeps the hardware out of the finished sightline. The family is offered in several arm lengths and finishes, making it practical to coordinate supports across counters with changing depths.
CounterBalance Extended Concealed Bracket Specifications
| Property | Detail |
|---|---|
| SKU | CCH-CBCBEM-18WH |
| Bracket family | Extended Concealed Bracket |
| Size | 18 inch |
| Width or mounting surface | 1 inch |
| Finish | white |
| Master weight | 3 lb |
| Master dimensions | 18 x 2 x 26 in |
| Mounting location | Load-bearing studs behind the finished wall |
Browse the countertop bracket category to compare neighboring sizes, profiles, and finishes. For product-family installation demonstrations and layout ideas, visit the CounterBalance application video library.
Need Help?
Need help coordinating bracket size, stud spacing, and sink hardware? Call (800) 220-1966 or email [email protected].
