CounterBalance Extended Concealed Bracket, White, 2 in x 9 in

Description

The CounterBalance Extended Concealed Bracket in White is a heavy-duty structural bracket built to carry floating countertop and bar-top overhangs without a visible support underneath. It mounts to load-bearing wall studs and adds a vertical extension above the horizontal support arm, which stiffens the bracket against the twisting load a long overhang puts on a single point of attachment.

Where the CounterBalance Extended Concealed Bracket Gets Used

This bracket is built for kitchen islands, waterfall countertops, and bar overhangs where the underside has to stay clean, with no legs or braces breaking up the sight line. The extended arm supports up to 6 inches of additional overhang beyond the standard Concealed Bracket, which matters on peninsula counters and bar seating where guests need knee room. White finish blends into painted cabinetry, white shaker millwork, and white quartz or solid-surface edges instead of standing out against the substrate it is meant to hide.

Installing the CounterBalance Extended Concealed Bracket

Mount the vertical leg to a load-bearing stud through the wall’s drywall or backing, then set the countertop onto the horizontal support arm so the finished stone or solid surface rests directly on the bracket. Because the bracket sits fully concealed inside the cabinet cavity or wall void, nothing is visible from the room side once installation is finished. Reference the CounterBalance load-limit chart for your specific span and material before finalizing bracket spacing, and consider the Hybrid Bracket instead if the drywall is already installed and stud access is limited.

Browse more sizes and finishes in our countertop brackets category. For installation walkthroughs and load-rating guidance, see the Chemical Concepts YouTube channel.

Need Help?

Need help sizing brackets for your overhang? Call (800) 220-1966 or email [email protected].
