Medmix Sulzer Mixpac MCH 06-24T Static Mixer (24 Element, 6mm)

Description

The MCH 06-24T Static Mixer is a 24-element, 6mm helical mixer for Sulzer Mixpac AC series two-component cartridges. It bonds to AC cartridges with the integral nut and works across the full AC family in both 1:1 and 2:1 ratios.

Key Features and Benefits

• 24 mixing elements for thorough activator and resin dispersion
• 6mm element diameter for precision bead control on smaller joints
• Integral nut mounting locks to AC series cartridges in seconds
• Stepped tip lets the operator change bead size by trimming the nozzle
• Compatible with epoxy, polyurethane, silicone, acrylic, and methacrylate adhesives
• Disposable single-use design avoids cleanup between bonds
• OEM Sulzer Mixpac (medmix) part, the brand specified by most AC cartridge manufacturers

Common Applications for MCH 06-24T Static Mixer

• Bonding aerospace and electronics components where small, precise beads are required
• Marine, trailer, and composite assembly using two-part epoxy or methacrylate
• Repair work in service shops running 200mL and 400mL AC cartridges
• Production lines that switch between 1:1 and 2:1 cartridges without changing nozzle
• Anchor and pin grouting where smooth, on-ratio output is required at the bond line

Compatible Cartridges

• Sulzer Mixpac AC 200mL cartridges, 1:1 and 2:1 ratios
• Sulzer Mixpac AC 400mL cartridges, 1:1 and 2:1 ratios
• Sulzer Mixpac AC 600mL cartridges, 1:1 and 2:1 ratios
• Sulzer Mixpac AC 1500mL cartridges, 1:1 and 2:1 ratios
• Compatible epoxy, polyurethane, silicone, acrylic, and methacrylate two-part adhesives

MCH 06-24T Static Mixer Technical Specifications

Packaging and Ordering

Sold individually and in bulk. For higher element counts or larger diameters, see the MCH 10-24T listing in the same MCH series. Manufacturer datasheets and the full Statomix line are documented on the Brandywine Mixers MCH product page.

Need Help?

Need a different element count, larger diameter, or a different mounting style? Call (800) 220-1966 or email [email protected]. We carry the full Sulzer Mixpac MCH, MFH, MFQX, and MBQ static mixer families.
