Description
QSil 266 is a two-component 100% silicone solids elastomer designed for electronic potting applications. The system offers a hard, thermally conductive, low modulus material that is readily repairable.
KEY FEATURES:
• 100% solids, no solvents
• Excellent thermal conductivity
| Uncatalyzed | |||||
| TEST | QSil 266 A | QSil 266 B | |||
| Appearance | Brown | Brown | |||
| Viscosity | 360 cps | 300 cps | |||
| Specific Gravity | 0.97 | 0.97 | |||
| Catalyzed | |
| MIX RATIO 1:1 by weight | |
| TEST | RESULT |
| Gel time at 25ºC | > 24 hours |
| Cured Properties | |
| 13 minutes at 150°C | |
| Durometer, Shore A | 60 |
| Tensile Strength | 200 psi |
| Elongation | 75% |
| Thermal Conductivity | ~ 0.84 W/m-K |
| Flammability (based on similar product performance) | 300 mm V-0 / 1.5 mm V-1 |
| Useful temperature range | -55°C – 204°C |
