Description
The ACF ORBIS 10-24 mixer is the matched static mix nozzle for Ritter ACF-coded 1:1 and 2:1 dual cartridges. With 24 mixing elements packed into a 156 mm housing on a 10 mm tube, it delivers the homogeneous bead industrial users expect from Ritter without overspecifying for adhesive systems that do not need the 10:1 ORBIS-X geometry.
Key Features and Benefits
- 24-element ORBIS static mix design for thorough two-component blending
- ACF coding fits only Ritter ACF-style cartridges, preventing wrong-mixer error
- Dialed in for 1:1 and 2:1 ratio adhesives, sealants, and potting compounds
- 10 mm tube diameter balances flow rate and mix quality
- Low retained-volume design reduces waste between dispenses
- Stocked in shop-friendly bag quantities for production lines
Common Applications for ACF ORBIS 10-24 Mixer
- Structural acrylic and epoxy bonding from 250 mL and 490 mL ACF cartridges
- Polyurethane potting and sealing in electronics assembly
- Composite repair where ratio precision matters
- Bonded panel assembly in trailer, RV, and modular building work
- R and D and prototype fixturing using small-volume ACF systems
Compatible Cartridges
- Ritter ACF 250 mL cartridges (PP and PBT)
- Ritter ACF 490 mL cartridges (PP and PBT)
- Ritter Coax 380 mL ACF cartridges, including the S variant
- Adhesive systems that ship from major brands in Ritter ACF format
ACF ORBIS 10-24 Mixer Technical Specifications
| Attribute | Value |
|---|---|
| Manufacturer | Ritter (Avantor) |
| Reference | 13600-2010 |
| Family | ACF ORBIS 10-24 |
| Mix ratios | 1:1 and 2:1 |
| Mixing elements | 24 |
| Length | 156 mm |
| Tube diameter | 10 mm |
| Outer outlet diameter | 5.4 mm reference (verify 1:1/2:1 outlet at order entry) |
| Coding | ACF (fits only ACF cartridges) |
Packaging and Ordering
Sold individually and in stocking quantities. For the 10:1 ratio variant of the same family, see the ACF ORBIS 10-24-X (13600-3101) page. Manufacturer specifications and the related ACF cartridge family are documented at ritter-cartridges.de.
Need Help?
Switching from a generic 24-element mixer to the ACF ORBIS 10-24 mixer? Our team can validate your cartridge coding and help you spec the right mixer count by adhesive viscosity. Call (800) 220-1966 or email [email protected].
