Huntsman Araldite HV 5309-2 Epoxy Hardener, 25 kg Pail

Description

HV 5309-2 hardener is the curing side for the Huntsman Araldite AV 5308 and HV 5309-2 two-component epoxy adhesive system. This 25 kg pail supports production bonding programs that need a toughened, non-sag paste adhesive for SMC, GRP, metals, and other dissimilar substrates.

HV 5309-2 hardener Benefits

• Matched hardener keeps the AV 5308 epoxy system aligned with Huntsman technical data.
• Paste system helps fill gaps and stay in place on vertical or uneven joints.
• Room-temperature cure supports shop bonding without a required oven cycle.
• Published data lists non-sag behavior up to 10 mm thickness for larger bond lines.
• Useful for transportation and composite programs where toughness and weather resistance matter.

Use this hardener only with the specified Araldite resin system and process documents. It is not a stand-alone adhesive, and the final bond performance depends on correct ratio control, surface preparation, mixing, and cure conditions.

HV 5309-2 hardener Applications

• Bonding sheet molding compound and glass-reinforced plastic parts.
• Structural adhesive work on transportation, rail, and composite assemblies.
• Gap-filling joints where a thixotropic epoxy paste is easier to control.
• Metal and plastic bonding programs qualified around Araldite AV 5308.
• Bulk production use where pail packaging is preferred over small cartridges.

Surface Preparation And Use

Clean and dry both bond surfaces before applying the mixed adhesive. Huntsman guidance calls for removing oil, grease, dirt, and other contaminants with an effective degreasing agent. For stronger and more durable joints, mechanically abrade or chemically treat the surface after degreasing, then clean again before bonding.

Mix and dispense according to the approved process for the AV 5308 system. Apply the adhesive to prepared joint surfaces, assemble parts promptly, and hold them in position until handling strength is reached. Do not use low-grade alcohol, gasoline, or paint thinner as surface cleaners for this adhesive process.

Technical Details And Documentation

Huntsman describes Araldite AV 5308 and Hardener HV 5309-2 as a two-component, room-temperature-curing epoxy paste for resilient bonding, with published ASTM D-1002 lap shear data on treated steel, stainless steel, and primed aluminum. Review current information from Huntsman before production use.

Ordering Help

For related epoxies, structural adhesives, mixers, and dispensing supplies, browse Chemical Concepts epoxy adhesives. For help matching resin, hardener, pack size, and cure schedule, call (800) 220-1966 or email [email protected].
