Description
Chem-Set VST 7825 is a 25 mil thick, double-coated acrylic foam tape designed for strong primerless bonding to low surface energy plastics including PP, PE, ABS, powder-coated metals, and clear-coated or ceramic-coated surfaces. Its soft, highly conformable acrylic foam core adapts to irregular surfaces while delivering excellent initial tack and long-term shear performance.
The 25 mil thickness makes VST 7825 ideal for general-purpose LSE bonding where more foam engagement is required than thinner constructions. This tape is widely used in automotive, industrial, and signage applications requiring strong, permanent, LSE-friendly adhesive performance.
VST 7825 is the Chem-Set equivalent to 3M LSE-060WF, offering similar LSE bonding capability with a conformable pure acrylic foam core.
Key Features and Benefits
-
Primerless bonding to LSE plastics including PP, PE, ABS
-
25 mil conformable acrylic foam for excellent surface wet-out
-
High shear strength for long-term durable assemblies
-
Strong initial tack for fast installation and production efficiency
-
Excellent UV, moisture, and temperature resistance
-
Suitable for automotive, powder coat, plastics, and signage applications
-
Chem-Set alternative to 3M LSE-060WF
Common Applications
-
Automotive trim and exterior plastics
-
Powder-coated metal bonding
-
Polypropylene (PP) and polyethylene (PE) components
-
Exterior and interior signage elements
-
Clear-coated or ceramic-coated surfaces
-
Plastics assembly and OEM production
Technical Specifications
(Derived from the manufacturer datasheet)
Performance
| Property | Value | Test Method |
|---|---|---|
| Peel Adhesion (SST) | 24 N/10 mm (14 lb/in) | ASTM D3330 |
| Peel Adhesion (ABS) | 39 N/10 mm (22 lb/in) | ASTM D3330 |
| Peel Adhesion (PP) | 14 N/10 mm (8 lb/in) | ASTM D3330 |
| Normal Tensile | 530 kPa (77 psi) | ASTM 897 |
| Dynamic Shear | 540 kPa (78 psi) | ASTM 1002 |
| Static Shear | >10,000 min at 22 C | ASTM 3654 |
Physical Properties
| Property | Value |
|---|---|
| Thickness | 0.024 inch (25 mils) |
| Density | 720 kg/m³ (45 lb/ft³) |
| Color | White |
| Adhesive | Double-coated acrylic |
| Foam Core | High conformable acrylic foam |
| Liner | Siliconized red PE film |
Temperature Resistance
| Condition | Rating |
|---|---|
| Long Term | 176 F (80 C) |
| Short Term | 212 F (100 C) |
| Minimum Temperature | -40 F (-40 C) |
Storage & Shelf Life
| Condition | Rating |
|---|---|
| Storage Temperature | 40 to 95 F (5–35 C) |
| Shelf Life | 24 months |
Available Sizes
Slit Rolls (Standard)
-
1/2 inch x 36 yd
-
3/4 inch x 36 yd
-
1 inch x 36 yd
Log Rolls
-
900 mm x 36 m
(Custom widths available)
Chem-Set LSE High Bond Tape Family Cross Reference
| Chem-Set Product | Thickness | LSE Application Class | Closest 3M LSE Equivalent |
|---|---|---|---|
| VST 7816 | 16 mils | Thin, conformable | No 3M equivalent |
| VST 7825 | 25 mils | Matches 3M LSE-060 class | 3M LSE-060WF |
| VST 7847 | 47 mils | Matches 3M LSE-110 class | 3M LSE-110WF |
| VST 7863 | 63 mils | Matches 3M LSE-160 class | 3M LSE-160WF |
Comparable Products
Chem-Set VST 7825 is frequently evaluated by buyers comparing LSE bonding tapes, including:
-
3M LSE-060WF
-
Primerless LSE acrylic foam tapes for PP, PE, ABS
-
Automotive-grade mounting tapes requiring strong initial tack
VST 7825 delivers similar LSE bonding performance while offering a cost-effective, technically robust solution for OEMs, fabricators, and sign manufacturers.
Ordering Information
Chem-Set VST 7825 is available in multiple widths and log formats. Custom slitting, production support, and technical assistance are available. Contact Chemical Concepts for pricing or application testing.
