Description
The Mixpac MBQX 05-16L is a disposable QUADRO static mixer for 4:1 and 10:1 B-System cartridges. It has 16 mixing elements in a 5.3 mm bore and measures 90.7 mm (3.57 in) overall, which makes it the shorter of the two sizes in the MBQX line. The dust grey collar with orange elements identifies it as the 4:1 and 10:1 version, and the luer slip outlet tip mates with syringe fittings and small dispensing accessories.
Specifications
| Property | Value |
|---|---|
| Model | MBQX 05-16L |
| Manufacturer part no. | 116063 |
| Mixing elements | 16 |
| Inner diameter | 5.3 mm (0.21 in) |
| Overall length | 90.7 mm (3.57 in) |
| Mix ratios | 4:1 and 10:1 |
| Element design | QUADRO, orange elements in a dust grey body |
| Outlet tip | Luer slip |
| Connection | B-System twist and lock, mounts directly to cartridge |
| Cartridge family | Mixpac B-System AB cartridges, 45 ml to 75 ml |
Where the 05-16L fits
- Shorter of the two MBQX sizes at 90.7 mm. Easier to handle in tight spots and on small assemblies where a longer nozzle gets in the way.
- 16 elements is the lower count in the line, which means less resistance at the gun. Useful on manual cartridge guns and on materials that blend without much shear.
- Retains less material than the 24 element version, which matters on a 45 ml or 50 ml cartridge where every milliliter counts.
- Same 5.3 mm bore as the 05-24L, so bead size and flow rate are identical between the two. Element count and length are the only difference.
- At 4:1 and especially 10:1 there is far less of the B side to distribute than at 1:1, so watch the mixed bead before settling on 16 elements for a new material.
- Mounts directly to the cartridge with a twist and lock connection. No converter, no retaining nut, no tools.
Compatible cartridges
| Cartridge system | Volume | Ratio | Mixpac article |
|---|---|---|---|
| B-System 50 Industrial | 50 ml | 4:1 | AB 050-04-10-01, AB 050-04-20-01 |
| B-System 50 Industrial | 45 ml | 10:1 | AB 050-10-10-01, AB 050-10-20-01 |
| B-System S50 Industrial | 50 ml | 10:1 | AB S50-10-20-01, AB S50-10-20-06 |
| B-System S75 Industrial | 75 ml | 10:1 | AB S75-10-20-02 |
Running a 1:1 or 2:1 B-System cartridge instead? Use the MBQ 05-16L with green elements. The ratios do not interchange.
Related B-System mixers
| Model | Elements | Length | Ratios | Choose it when |
|---|---|---|---|---|
| MBQX 05-16L (this page) | 16 | 90.7 mm | 4:1, 10:1 | Shorter nozzle, less resistance, less material retained |
| MBQX 05-24L | 24 | 122 mm | 4:1, 10:1 | Material streaks or cures unevenly at 16 elements |
| MBQ 05-16L | 16 | 90.7 mm | 1:1, 2:1 | Same nozzle, different ratio. Green elements. |
| MBQ 05-24L | 24 | 122 mm | 1:1, 2:1 | Longer nozzle for 1:1 and 2:1 cartridges |
See the full MBQX size chart for both models with lengths, bores, and retained volumes.
Common applications
- Small-batch and repair bonding from 45 ml, 50 ml, and 75 ml cartridges
- Off-ratio two-part chemistries that ship in 4:1 and 10:1 cartridges
- Electronics and small component assembly where a fine bead is needed
- Sample and trial dispensing before committing to a production cartridge size
- Field service and maintenance work with portable cartridge guns
- Dispensing epoxy, polyurethane, silicone, acrylic, and MMA two-part adhesives and sealants
Ordering
The MBQX 05-16L is stocked and sold individually, so you can order one to check fit or test a material before buying a larger quantity. Pair it with matching B-System cartridges and dispensing guns from the dispensers, mixers, and nozzles category.
Frequently asked questions
What cartridges does the MBQX 05-16L fit?
Mixpac B-System AB cartridges in 4:1 and 10:1 ratios, covering the 50 ml 4:1, the 45 ml and 50 ml 10:1, and the 75 ml 10:1 sizes. It does not fit F-System 200 or 400 series cartridges, which use the MFQX instead.
What does MBQX 05-16L mean?
MBQ is mixer, B-System, QUADRO design. The X marks the 4:1 and 10:1 version with orange elements. The 05 is the inner diameter rounded down, actually 5.3 mm. The 16 is the number of mixing elements. The L is the luer slip outlet tip.
Should I use the 05-16L or the 05-24L?
Start with the 05-16L. Both have the same 5.3 mm bore and the same luer slip tip, so bead size and flow rate are identical. The 05-24L adds eight mixing elements for materials that streak or cure unevenly at 16. The tradeoff is 31 mm more nozzle length, more resistance at the gun, and more material left in the nozzle.
How do I tell an MBQX from an MBQ?
Element color. MBQX has orange elements and fits 4:1 and 10:1 cartridges. MBQ has green elements and fits 1:1 and 2:1. Both use the same dust grey collar and the same dimensions, so color is the only thing to check against the ratio printed on your cartridge.
Can I buy a single MBQX 05-16L?
Yes. It is stocked and sold individually, so you can order one to check fit or test a material before buying a larger quantity.
Does this nozzle need a converter or retaining nut?
No. The MBQX mounts directly to the B-System cartridge with a twist and lock connection. No converter, no retaining nut, no tools.
